Video Intercom, Tuya, Wi-Fi, 2-juhtmeline

Video Intercom, Tuya, Wi-Fi, 2-Wire

The set includes outdoor unit (doorbell color camera 1080p, 110° coverage, with IR night vision, IP55, two-wire connection) and indoor unit (RGB monitor with LCD touch screen 7-inch diagonal, 1024×600 resolution, white color, Wi-Fi)


Features:
The video intercom allows you to conveniently manage smart homes by controlling access to the premises.
The device allows you to see arriving visitors and talk to them live, let them in or reject a request for strangers or unwanted persons to enter the house or plot with the help of one button.
Unlocking the door or gate is controlled via the internal monitor or remotely via the smart Tuya app (via phone, tablet).
The built-in 1080P HD color camera allows you to monitor everything that happens outside the door, transmitting the image to the indoor monitor or Tuya app. Night vision allows you to monitor and record the image at night.
2.4GHz Wi-Fi connection is used, the Tuya app supports Android or iOS smart devices.
The indoor monitor 7”, with a color LCD touch screen with a resolution of 1024×600, can display a live image, capture photos and videos, view them, adjust the volume, unlock the door or gate with one click, and control other settings.
The monitor has an ambient LED lighting function.
The camera viewing angle is up to 110° horizontally, up to 65° vertically.
Door and gate opening is supported.
Relay lock control.
Two-way talk.
Built-in speaker.
Mechanical call button.
The intercom supports IR night vision.
Supports PAL format.
Storage: micro SD card up to 128GB. Note: micro SD card is purchased separately.


Specifications:
Power adapter input: AC 100-240V, 50/60Hz, 0.8A.
Power adapter output: DC 15V 1.2A.
Power consumption: Standby mode: <3W, Working mode max.: <9W. Monitor diameter: 7 inches. Monitor resolution: RGB 1024x600 pixels. TF card capacity: up to 128GB (purchased separately). Call / conversation volume: 75-85dB (30cm distance). Photo size: 25kb, jpg format. Video: 52kb, mp4 format, max. recording time 120s. App: Tuya Smart / Smart Life (Android, iOS). Wi-Fi connection frequency: 2.4GHz. Camera resolution: 1080p. Viewing angle: up to 110° (H), up to 65° (V). IR LED: 940nm. Unlocking distance: 0-10m. Electric lock voltage/current: DC 12V/3A max. Indoor unit dimensions: 117.7mm×174.2mm×21.9mm. Indoor unit operating temperature: -10°~+50°C. Outdoor unit dimensions: 134mm×48mm×40mm. Outdoor unit operating temperature: -20°~+50°C. Operating humidity: 10-90%RH. Protection class: IP55. Intercom color: gray, black. Monitor color: white. Installation: surface-mounted. Weight: indoor unit: 346g, outdoor unit: 169g, 197g with bracket.

The set includes:
Outdoor unit.
Rainshade bracket.
Indoor unit.
Monitor bracket.
Power adapter.
2-wire cable 15m.
Mounting screw set.
User manual.


Warranty: 24 months.
